Lithium Based Molecular Sieve for seperate Nitrogen and Oxygen from Air

Name: Lithium Based Molecular Sieve for seperate Nitrogen and Oxygen from Air
Brand: NAIKE
Price: 22 USD

Brand Name : NAIKE

Model Number : NKOX-103

Certification : SGS

Place of Origin : JIANGXI

MOQ : 100kg (Min. Order)

Price : USD22-USD35

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram, L/C, D/A

Supply Ability : 200 TON per Month

Delivery Time : 3-4 work day

Packaging Details : drum

Purity : 99.9%

Classification : Catalyst

Other names : ultra stable y zeolite

Type : Adsorbent

Cas no. : No

Usage : Water Treatment Chemicals,Plastic Auxiliary Agents

Adsorbent variety : Molecular Sieve

Function : catalyst

Application : Chemical Catalyst,FCC,Desiccant

Shape : sphere

Contact Now

Description
It is a high performance lithium exchanged low silica form of the X-type zeolite with exceptional nitrogen capacity to provide optimal performance in the separation of oxygen fromair in medical oxygen concentrators. It is developed and designed for the production of up to 95% oxygen rich air streams in medical oxygen concentrators with air flows up to 10 liters per minute.There are three mechanisms of adsorption separation: steric hindrance effect, kinetic effect and equilibrium effect.
specification
The test items	unit	the first			note
The test items	unit	NKOX-100	NKOX-101	NKOX-103	note
Particle size	mm	1.6-2.5	0.4-0.8	1.3-1.7	~
Static nitrogen adsorption	NK/kg	≥22	≥23	≥22	1bar , 25°C
Nitrogen/oxygen separation coefficient	~	≥6.2	≥6.3	≥6.2	1bar, 25°C
Crushing Strength	N	≥25	~	≥15	The average
Bulk density	g/ml	≥0.62	≥0.62	≥0.61
Screening	%wt	≥97	≥95	≥95	Standard screen
Water content	%wt	≤0.5	≤0.5	≤0.5	K.E.(550°C)

Application
steel, nonferrous metallurgy, chemical industry, furnaces energy saving, environmental protection, paper making, aquaculture, health care.
Characteristics
Lithium based molecular sieve is a synthetic zeolite of lithium-type crystal structure, large Nitrogen adsorption capacity, high efficiency of oxygen/nitrogen separation.
In addition to ethanol, a well-designed and manufactured sieve is not only used to dehydrate the ethanol hydrated vapors, but is highly useful for dehydrating other types of chemicals too. Thus, gives a facility to use this system in future operations as well.
It shows high N2/O2 separation under a very low pressure, which lowers the consumption of producing oxygen.
The advantage of on the equilibrium adsorption capacity, It applies to various VPSA device for producing oxygen.

Lithium Based Molecular Sieve for seperate Nitrogen and Oxygen from Air
